2024 Mondraker Foxy R Alloy Bike
Regular price £4,699.00 Sale price £3,289.00 Save £1,410.00
-
Frame
Foxy 29 6061 Alloy Stealth Evo, hydroformed tubing, Zero Suspension System, 150mm travel, Forward Geometry, one piece Monoblock upper link, Boost 12x148mm rear axle, tapered head tube, 73mm BSA bottom bracket, dedicated 1x drivetrain design, telescopic seatpost internal routing, MAX capacity sealed bearings, ISCG 05
Sizes
S: 380mm / M: 420mm / L: 470mm / XL: 510mm
-
Rear shock
Öhlins TTX Air 205x65mm. Settings: high speed compression lever with climb mode, low-speed compression, rebound, air preload. Trunnion top mount, 25x8mm bottom bushings
Shock settings
C20 compression, R35 rebound
-
Fork
Öhlins RXF 36 M.3 29, 160mm, TTX18 Twin Tube cartridge, tapered steerer tube, Boost 15x110mm axle, offset 44mm. Settings: high speed compression lever with climb mode, low-speed compression, rebound, air preload, ramp chamber. Fork settings: C20 R40
Headset
Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º
-
Stem
Onoff Sulfur FG 30mm 0º, 6061 forged alloy, 31.8mm barbore
Handlebar
Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore
-
Grips
Onoff Twin, 1lock-on, 135mm
Seatpost
Onoff Pija dropper internal, diameter 31.6mm, 1X Remote lever with bearing, S size: 405x95-125mm, M size: 458x120-150mm, L size: 498x140-170mm, XL size: 558x170-200mm
-
Saddle
SDG BEL-AIR 3.0, LPU foam, steel rails
Front brake
Sram Code Bronze Stealth, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads
-
Rear brake
Sram Code Bronze Stealth, 4-piston caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pads
Brake lever
Sram Code Bronze Stealth, SwingLink and lever pivot bushings, tool-free reach adjust
-
Rims
e*thirteen LG1 Enduro, IW30 Hookless, 6069 Welded Aluminum, 30mm internal width, tubeless ready, 28 spokes
Spokes
e*thirteen custom Hive triple-butted black steel, alloy nipples, nipple washers
-
Front hub
e*thirteen Boost 15x110mm, triple-sealed, fully machined aluminum, IS 6 bolts
Rear hub
e*thirteen Boost 12x148mm, triple-sealed, fully machined aluminum w/6-degree engagement, IS 6 bolts, HG freehub
-
Front tire
Maxxis Minion DHF 29x2.5 WT, tubeless ready, 3C MAXX TERRA compound, EXO+ protection, 120TPI, folding bead
Rear tire
Maxxis Aggressor 29x2.3, tubeless ready, dual compound, Exo protection, 60TPI, folding bead
-
Crankset
Sram SX Eagle, Boost, DUB axle, Direct Mount chain ring, S size: 170mm M size: 175mm L size: 175mm XL size: 175mm, CL55
Rings
32T, CNC-machined alloy, X-SYNC 2
-
Bottom bracket
Sram DUB BSA, sealed bearings, 73mm
Chain
Sram SX Eagle, 12s, Powerlock
-
Rear derrailleur
Sram NX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1
Shift levers
Sram Trigger SX Eagle, 12s, X-Actuation 1:1
-
Casette
Sram PG-1230, 11-50T, 12s
Derailleur hanger
Sram UDH
-
Weight
16,2 kg
Geometry
FRAME SIZES M L A Seattube length 375mm 415mm 445mmm 500mm B Toptube length 600mm 622mm 647mm 670mm C Bottom bracket drop -22mm/-27mm -22mm/-27mm -22mm/-27mm -22mm/-27mm D Bottom bracket height 350mm/345mm 350mm/345mm 350mm/345mm 350mm/345mm E Chainstay length 438mm/345mm 438mm/445mm 438mm/445mm 445mm F Seat tube angle 71º/70.5º 71º/70.5º 71º/70.5º 71º/70.5º G Effective seattube angle 77°/76.5º 77°/76.5º 77°/76.5º 77°/76.5º H Headtube angle 64.5º/64º 64.5º/64º 64.5º/64º 64,5º I Fork Offset 44mm 44mm 44mm 44mm J Wheelbase 1210mm/1216mm 1233mm/1239mm 1260mm/1267mm 1286mm/1292mm K Headtube length 100mm 100mm 120mm 120mm L Reach 445mm/440mm 465mm/460mm 485mm/480mm 505mm/500mm M Stack 617mm 617mm 647mm 647mm
