2024 Ibis Cycles HD6 GX Bike
Regular price £5,699.00 Sale price £4,999.00 Save £700.00
The HD6 is the evolution of one of the most successful enduro bikes in history. Designed with input from our Enduro World Cup team and building upon our award-winning Ripmo and HD lines, the HD6 features increased travel, a completely redesigned suspension layout, and mixed wheels.
The 29" front wheel, bolstered by 180mm of travel, assures stability, whereas the 27.5" rear wheel allows for additional maneuverability. The 165mm of travel skillfully manages any fallout. With a 64 degree head tube angle (one degree slacker than the current Ripmo), a BB height similar to Mojo HD5, and chainstay length identical to the current Ripmo (despite the 27.5" rear wheel), the bike maintains an equilibrium between agility and stability.
In order to place every size rider in the same position over the rear wheel, the HD’s seat tube angles get steeper as frame size increases. With four sizes, this would have resulted in larger jumps in reach, so we added a fifth size. The smaller increments across five sizes means that you can find just the right size. We encourage riders to choose their bike size based on their desired reach and top tube measurements.
Our upper link suspension layout is progressive enough to be sensitive off the top, yet supportive enough for the biggest hits. It is also compatible with all coil shocks, for those longer race stages that can tax air shock performance.
The suspension layout may be new, but it’s still DW-Link. The inherent efficiency means you don’t need an overdamped shock to climb well. Less shock damping allows the wheels to stay planted on the ground, providing more traction and that hover-bike feel that our frames are known for. The HD6 climbs with a finesse that defies its enduro race pedigree.
Tired of buying bearings each season? So were we. That's why we've strategically employed bushings where they're most effective and bearings elsewhere. The IGUS bushings in our lower link are not only lighter and stiffer, they're virtually maintenance-free. We believe so strongly in them, we back them with free lifetime replacement.
If it's our fault, we'll fix it. Simple as that.
| NOMINAL SIZE | SM | MD | XM | LG | XL | |
|---|---|---|---|---|---|---|
| Seat Tube Length | A | 400 | 400 | 406 | 450 | 470 |
| Top Tube Length | B | 585 | 610 | 630 | 655 | 685 |
| Head Tube Length (4mm stack of lower cup not included) | C | 81 | 86 | 91 | 100 | 115 |
| Chainstay Length | D | 435 | 435 | 435 | 435 | 435 |
| Seat Tube Angle | E | 76° | 76° | 76.5° | 77° | 77.5° |
| Head Tube Angle | G | 64° | 64° | 64° | 64° | 64° |
| Wheelbase | H | 1202 | 1228 | 1256 | 1288 | 1328 |
| BB Height (with 2.5WT Maxxis Assegai tires) | 345 | 345 | 356 | 345 | 345 | |
| BB Drop | K | 30 | 30 | 30 | 30 | 30 |
| Stack | I | 621 | 625 | 630 | 638 | 651 |
| Reach | J | 430 | 454 | 480 | 508 | 541 |
| Saddle height for seat tube angle | F | 650 | 700 | 745 | 790 | 830 |
| Standover | L | 725 | 735 | 752 | 765 | 769 |
| Trail | 136 | 136 | 136 | 136 | 136 | |
| Fork Offset | 44 | 44 | 44 | 44 | 44 |
| COMPONENT | STANDARD COMPONENT | UPGRADE / OPTION |
|---|---|---|
| Fork | Fox Float 38 Factory Series, 180mm, 29”, 110x15 | |
| Shock | Fox Float X2 Factory Series with EVOL, 230mm x 65mm | |
| Wheels | Blackbird Send Alloy 29/27.5 | |
| Tires (F/R) | Maxxis Assegai, 29” x 2.5” / Maxxis DHR, 27.5” x 2.4” | |
| Brakes | SRAM Code RSC, 4 Piston | |
| Rotors (F/R) | SRAM Centerline 200 | |
| Crankset | SRAM NX Eagle, DUB, 32T Alloy Ring | |
| Bottom Bracket | SRAM DUB BSA | |
| Rear Derailleur | SRAM GX Eagle | |
| Shifter | SRAM NX Eagle | |
| Cassette | SRAM XG 1275, 10-52T | |
| Chain | SRAM NX Eagle | |
| Chain Guide | MRP AMg SE | |
| Headset | Cane Creek 40 ZS44/ZS56 | |
| Grips | Lizard Skin Charger | |
| Handlebar | Ibis Aluminum, 780mm | |
| Stem | Ibis 31.8mm
S–M: 40mm, L–XL: 50mm |
|
| Seatpost | KS Rage-i Dropper 31.6mm
S: 125mm, M: 150mm, XM: 170mm, L–XL: 190mm |
|
| Saddle | WTB Silverado, 142mm |
Images may not show actual build kit content. Pricing and specifications subject to change without notice.
