Mondraker

2024 Mondraker Chaser

£4,499.00 £2,999.00 Save £1,500.00

Tax included. Shipping calculated at checkout.

Frame

Chaser 6061 Alloy Stealth Evo, e-Bike Optimized Zero Suspension System, 150mm travel, Forward Geometry, internal removable battery, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 17mm axles, integrated dropout speed sensor, exclusive plastic motor covers, shock mudguard

Sizes

S: 380mm / M: 420mm / L: 450mm / XL: 490mm
Rear shock

RockShox Deluxe Select R DebonAir, 205x65mm. Settings: Low-speed rebound, air preload. Trunnion top mount, 25x10mm bottom bushings

Shock settings

Light compression, Linear rebound, 1 Token
Fork

RockShox 35 Silver TK 29, 160mm, TurnKey, Solo Air, tapered steerer tube, Boost 15x110mm axle, 35mm steel stanchions, 44mm offset. Settings: compression adjustment at low-speed to lock, rebound, air preload

Headset

Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º
Stem

Onoff Sulfur FG 30mm 0º, 6061 forged alloy, 31.8mm barbore

Handlebar

Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore
Grips

Onoff Twin, 1lock-on, 135mm

Seatpost

Onoff Pija dropper internal, diameter 31.6mm, 1X Remote lever with bearing, S size: 405x95-125mm, M size: 458x120-150mm, L size: 498x140-170mm, XL size: 558x170-200mm
Saddle

MDK ebike black

Front brake

Sram DB8, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads
Rear brake

Sram DB8, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads

Brake lever

Sram DB8, tool reach adjust, lever pivot bushings
Rims

Mavic E-CrossRide 29, 30mm internal width, welded, PFP, tubeless ready, 28 spokes

Spokes

Mavic J-bend double butted, contactless lacing
Front hub

Mavic, Boost 15x110mm, IS 6 bolts

Rear hub

Mavic, Boost 12x148mm, ID360 Ratched system, IS 6 bolts, HG freehub
Front tire

Maxxis Rekon 29x2.6, tubeless ready, dual compound, EXO protection, 60TPI, folding bead

Rear tire

Maxxis Rekon 29x2.6, tubeless ready, dual compound, EXO protection, 60TPI, folding bead
Crankset

Race Face Aeffect ebike, 165mm

Rings

Sram X-Sync 2 Eagle 34T, steel, narrow-wide, 104 BCD
Chain

Sram SX Eagle, 12s, Powerlock

Rear derrailleur

Sram SX Eagle, Type 3 roller bearing clutch, cage lock, long cage, 1x12s, X-actuation 1:1
Shift levers

Sram Trigger SX Eagle, 12s, X-Actuation 1:1, single click

Casette

Sram PG-1210, 11-50T, 12s
Derailleur hanger

Mondraker M068

Weight

25,4 kg
Display

Bosch Intuvia 100 / Bosch Mini Remote / Bosch System Controller

Motor

Bosch Performance Line CX Cruise (25Km/h) GEN4 SMART SYSTEM

Battery

Bosch Powertube 625Wh

Geometry

Frame size		S	M	L
A	Seattube length	380mm	420mm	450mm	490mm
B	Toptube length	605mm	625mm	650mm	670mm
C	Bottom bracket drop	-25mm	-25mm	-25mm	-25mm
D	Bottom bracket height	350mm	350mm	350mm	350mm
E	Chainstay length	455mm	455mm	455mm	455mm
F	Seat tube angle	73.5°	73.5°	73.5°	73.5°
G	Effective seattube angle	76°	76°	76°	76°
H	Headtube angle	65.5°	65.5°	65.5°	65.5°
I	Fork Offset	44mm	44mm	44mm	44mm
J	Wheelbase	1225mm	1245mm	1265mm	1285mm
K	Headtube length	110mm	110mm	130mm	130mm
L	Reach	450mm	470mm	490mm	510mm
M	Stack	622mm	622mm	640mm	640mm

Mondraker

2024 Mondraker Foxy R Alloy Bike

£4,699.00 £3,289.00 Save £1,410.00

Tax included. Shipping calculated at checkout.

Frame

Foxy 29 6061 Alloy Stealth Evo, hydroformed tubing, Zero Suspension System, 150mm travel, Forward Geometry, one piece Monoblock upper link, Boost 12x148mm rear axle, tapered head tube, 73mm BSA bottom bracket, dedicated 1x drivetrain design, telescopic seatpost internal routing, MAX capacity sealed bearings, ISCG 05

Sizes

S: 380mm / M: 420mm / L: 470mm / XL: 510mm
Rear shock

Öhlins TTX Air 205x65mm. Settings: high speed compression lever with climb mode, low-speed compression, rebound, air preload. Trunnion top mount, 25x8mm bottom bushings

Shock settings

C20 compression, R35 rebound
Fork

Öhlins RXF 36 M.3 29, 160mm, TTX18 Twin Tube cartridge, tapered steerer tube, Boost 15x110mm axle, offset 44mm. Settings: high speed compression lever with climb mode, low-speed compression, rebound, air preload, ramp chamber. Fork settings: C20 R40

Headset

Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º
Stem

Onoff Sulfur FG 30mm 0º, 6061 forged alloy, 31.8mm barbore

Handlebar

Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore
Grips

Onoff Twin, 1lock-on, 135mm

Seatpost

Onoff Pija dropper internal, diameter 31.6mm, 1X Remote lever with bearing, S size: 405x95-125mm, M size: 458x120-150mm, L size: 498x140-170mm, XL size: 558x170-200mm
Saddle

SDG BEL-AIR 3.0, LPU foam, steel rails

Front brake

Sram Code Bronze Stealth, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads
Rear brake

Sram Code Bronze Stealth, 4-piston caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pads

Brake lever

Sram Code Bronze Stealth, SwingLink and lever pivot bushings, tool-free reach adjust
Rims

e*thirteen LG1 Enduro, IW30 Hookless, 6069 Welded Aluminum, 30mm internal width, tubeless ready, 28 spokes

Spokes

e*thirteen custom Hive triple-butted black steel, alloy nipples, nipple washers
Front hub

e*thirteen Boost 15x110mm, triple-sealed, fully machined aluminum, IS 6 bolts

Rear hub

e*thirteen Boost 12x148mm, triple-sealed, fully machined aluminum w/6-degree engagement, IS 6 bolts, HG freehub
Front tire

Maxxis Minion DHF 29x2.5 WT, tubeless ready, 3C MAXX TERRA compound, EXO+ protection, 120TPI, folding bead

Rear tire

Maxxis Aggressor 29x2.3, tubeless ready, dual compound, Exo protection, 60TPI, folding bead
Crankset

Sram SX Eagle, Boost, DUB axle, Direct Mount chain ring, S size: 170mm M size: 175mm L size: 175mm XL size: 175mm, CL55

Rings

32T, CNC-machined alloy, X-SYNC 2
Bottom bracket

Sram DUB BSA, sealed bearings, 73mm

Chain

Sram SX Eagle, 12s, Powerlock
Rear derrailleur

Sram NX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1

Shift levers

Sram Trigger SX Eagle, 12s, X-Actuation 1:1
Casette

Sram PG-1230, 11-50T, 12s

Derailleur hanger

Sram UDH

Weight

16,2 kg

Geometry

FRAME SIZE		S	M	L
A	Seattube length	375mm	415mm	445mmm	500mm
B	Toptube length	600mm	622mm	647mm	670mm
C	Bottom bracket drop	-22mm/-27mm	-22mm/-27mm	-22mm/-27mm	-22mm/-27mm
D	Bottom bracket height	350mm/345mm	350mm/345mm	350mm/345mm	350mm/345mm
E	Chainstay length	438mm/345mm	438mm/445mm	438mm/445mm	445mm
F	Seat tube angle	71º/70.5º	71º/70.5º	71º/70.5º	71º/70.5º
G	Effective seattube angle	77°/76.5º	77°/76.5º	77°/76.5º	77°/76.5º
H	Headtube angle	64.5º/64º	64.5º/64º	64.5º/64º	64,5º
I	Fork Offset	44mm	44mm	44mm	44mm
J	Wheelbase	1210mm/1216mm	1233mm/1239mm	1260mm/1267mm	1286mm/1292mm
K	Headtube length	100mm	100mm	120mm	120mm
L	Reach	445mm/440mm	465mm/460mm	485mm/480mm	505mm/500mm
M	Stack	617mm	617mm	647mm	647mm

Mondraker

2024 Mondraker Prime EMTB

£3,499.00 £2,499.00 Save £1,000.00

Tax included. Shipping calculated at checkout.

If you're looking for an Ebike that you can commute to work on in the morning and then take the path back through the forest on the way home for some fun then the Mondraker Prime is for you!

Frame

Prime Xtralite 6061 Fully Butted Alloy, Forward Geometry, internal removable battery, tapered head tube, Boost 12x148mm rear axle, integrated dropout speed sensor

Sizes

XS: 380mm / S: 390mm / M: 430mm / L: 470mm / XL: 510mm

Fork

RockShox Recon Silver RL 29, 120mm, Motion control, Solo Air, tapered steerer tube, Boost 15x110mm axle, 32mm steel stanchions, 42mm offset. Settings: compression adjustment at low-speed to lock, rebound, air preload

Headset

Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º

Stem

Onoff Sulfur FG 30mm 0º, 6061 forged alloy, 31.8mm barbore

Handlebar

Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore

Grips

Onoff Twin, 1lock-on, 135mm

Seatpost

Onoff Sulfur 0-R, 6061 T6 Alloy, 3D forged, diameter 31.6mm, length 400mm

Saddle

MDK ebike black

Front brake

Sram Level T, 2 piece caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pad

Rear brake

Sram Level T, 2 piece caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pad

Brake lever

Sram Level T, Direct Link actuation, tooled reach adjust, lever pivot bushings

Rims

MDK-HP1 29, 30mm internal width, tubeless ready, 32 spokes

Spokes

CN round stainless steel

Front hub

Formula DC711, Boost 15x110mm, sealed bearings, IS 6 bolts
Rear hub

Formula EHL148 Boost 12x148mm, sealed bearings, IS 6 bolts

Front tire

Maxxis Rekon 29x2.6, tubeless ready, dual compound, EXO protection, 60TPI, folding bead

Rear tire

Maxxis Rekon 29x2.6, tubeless ready, dual compound, EXO protection, 60TPI, folding bead

Crankset

Race Face Aeffect ebike, 165mm

Rings

Sram X-Sync 2 Eagle 34T, steel, narrow-wide, 104 BCD

Chain

Sram SX Eagle, 12s, Powerlock

Rear derrailleur

Sram SX Eagle, Type 3 roller bearing clutch, cage lock, long cage, 1x12s, X-actuation 1:1

Shift levers

Sram Trigger SX Eagle, 12s, X-Actuation 1:1, single click

Casette

Sram PG-1210, 11-50T, 12s

Derailleur hanger

Mondraker M068

Weight

22,5 kg

Display

Bosch Kiox 300 / Bosch Led Remote

Motor

Bosch Performance Line CX (25km/h) Smart System

Battery

Bosch Powertube 625Wh

Mondraker

2024 Mondraker Raze Alloy Bike

£2,999.00 £2,099.00 Save £900.00

Tax included. Shipping calculated at checkout.

PERFECT FOR RIDERS WHO WANT A BIKE THAT OFFERS THE WHOLE PACKAGE AT A REASONABLE PRICE

Name: 2024 Mondraker Chaser
Brand: Mondraker
Price: 2999.0 GBP
Availability: InStock

Perfect for riders who want a bike that offers the whole package at a reasonable price. The RAZE is the trail bike to offer you the most amazing performance in its category thanks to Mondraker’s exclusive technologies: ALLOY STEALTH EVO, FORWARD GEOMETRY and ZERO SUSPENSION SYSTEM, and all without breaking the bank. Along with the other models in the range, whether carbon or aluminium, the RAZE builds on that same philosophy of enjoying both the ups and the downs thanks to its abundant capabilities at both activities. With 150mm of travel up front and 130mm at the rear, you'll be amazed at how versatile and fun it is. It is truly a bike for everything. The definitive quiver killer.

COMPONENTS

TECHNICAL SPECS

Frame

Raze 29 6061 Alloy Stealth Evo, hydroformed tubing, Zero Suspension System, 130mm travel, Forward Geometry, one piece Monoblock upper link, Boost 12x148mm rear axle, tapered head tube, 73mm BSA bottom bracket, dedicated 1x drivetrain design, telescopic seatpost internal routing, MAX capacity sealed bearings, ISCG 05

Sizes

S: 380mm / M: 420mm / L: 470mm / XL: 510mm
Rear shock

Fox Float DPS LV EVOL Performance, 205x57.5mm. Settings: rebound, 3-position compression adjustment (Open/Mid/Lock), air preload. Trunnion top mount, 25x8mm bottom bushings

Shock settings

Light compression, light rebound, air volume spacer 0.6
Fork

RockShox 35 Gold 29 RL, 150mm, Solo Air, tapered steerer tube, Boost 15x110mm axle, 35mm steel stanchions, 44mm offset. Settings: compression adjustment at low-speed to lock, rebound, air preload

Headset

ONOFF Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º
Stem

ONOFF Sulfur FG 30mm 0º, 6061 forged alloy, 31.8mm barbore

Handlebar

ONOFF Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore
Grips

ONOFF Twin, 1lock-on, 135mm

Seatpost

ONOFF Pija dropper internal, diameter 31.6mm, S size: 405x95-125mm, M size 458x120-150mm, L size: 498x140-170mm, XL size: 498x140-170mm
Saddle

MDK series PU 2023

Front brake

Sram Level T, 2 piece caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pad
Rear brake

Sram Level T, 2 piece caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pad

Brake lever

Sram Level T, Direct Link actuation, tooled reach adjust, lever pivot bushings
Rims

MDK-EP1 29, 30mm internal width, tubeless ready, 32 spokes

Spokes

CN round stainless steel
Front hub

Formula DC711, Boost 15x110mm, sealed bearings, IS 6 bolts

Rear hub

Formula DHT148 Boost 12x148mm, sealed bearings, IS 6 bolts
Front tire

Maxxis Dissector 29x2.4 WT, tubeless ready, 3C MAXX TERRA compound, EXO+ protection, 120TPI, folding bead

Rear tire

Maxxis Aggressor 29x2.3, tubeless ready, dual compound, Exo protection, 60TPI, folding bead
Crankset

Sram SX Eagle, Boost, DUB axle, Direct Mount chain ring, S/M size: 170mm, L/XL size: 175mm

Rings

32T, steel, X-Sync 2
Bottom bracket

Sram DUB BSA, sealed bearings, 73mm

Chain

Sram SX Eagle, 12s, Powerlock
Rear derrailleur

Sram SX Eagle, Type 3 roller bearing clutch, cage lock, long cage, 1x12s, X-actuation 1:1

Shift levers

Sram Trigger SX Eagle, 12s, X-Actuation 1:1
Casette

Sram PG-1210, 11-50T, 12s

Derailleur hanger

Sram UDH

Weight

15,9 kg

Geometry

FRAME SIZE		S	M	L
A	Seattube length	375 mm	4515 mm	445 mm	490 mm
B	Toptube length	594 mm	614 mm	638 mm	658 mm
C	Bottom bracket drop	-29 mm	-29 mm	-29 mm	-29 mm
D	Bottom bracket height	340 mm	340 mm	340 mm	340 mm
E	Chainstay length	435 mm	435 mm	435 mm	435 mm
F	Seat tube angle	72º	72º	72º	72º
G	Effective seattube angle	76.5º	76.5º	76.5º	76.5º
H	Headtube angle	65.5º	65.5º	65.5º	65.5º
I	Fork Offset	44 mm	44 mm	44 mm	44 mm
J	Wheelbase	1197 mm	1216 mm	1246 mm	1266 mm
K	Headtube length	100 mm	100 mm	120 mm	120 mm
L	Reach	450 mm	470 mm	490 mm	510 mm
M	Stack	623 mm	623 mm	641 mm	641 mm

2024 Mondraker Summum Carbon R 29" Downhill Bike

Mondraker

2024 Mondraker Summum Carbon R 29" Downhill Bike

£7,699.00 £3,999.00 Save £3,700.00

Tax included. Shipping calculated at checkout.

The SUMMUM CARBON R inherits all of the features from the CARBON RR

The SUMMUM CARBON R inherits all of the features from the CARBON RR but with more affordable components. It shares the same frame as the CARBON RR, and also offers the MX option with a 29" front wheel and a 27.5" rear wheel. Light and effective, it's a great bike for podium finishes in any DH race. In this case the geometry change kit is optional.

Components

Technical specs

Frame

Summum Carbon Stealth Air full Carbon, Zero Suspension System, 200mm travel, Forward Geometry, Carbon Monoblock upper link, SuperBoost 12x157mm rear axle, 83mm BSA bottom bracket, HHG internal cable routing, MAX. capacity dual row Enduro bearings, shock mudguard, ISCG 05, custom frame protectors. *Optional Geometry kit.

Sizes

S / M / L / XL 29" and MX
Rear shock

Fox DHX2 Performance Elite, 225x70mm. Settings: low-speed compression, low-speed rebound, spring preload. Trunnion top mount, 30x8mm bottom bushings

Shock settings

ECC010 compression, ECR012 rebound. Spring rate: S size 400 lbs, M size 450 lbs, L/XL size 500 lbs
Fork

Fox 40 29 Float FIT GRIP EVOL Performance, 203mm, air spring, 1-1/8” steerer tube, 20x110mm axle, offset 56mm. Settings: low-speed compression, low-speed rebound, air preload

Headset

ONOFF Mercurium 1.5 ZS for 1-1/8” steerer tube, 41x30.15x7x45ºx45º ACB sealed bearings, geometry kit cups, external diameter 56mm
Stem

ONOFF Krypton DH CNC Integrated FG, 25-30mm adjustable length, 31.8mm barbore, 6061 alloy, 2x6mm spacer

Handlebar

ONOFF Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore
Grips

ONOFF Desert, 1lock-on, 135mm

Seatpost

SDG Micro I-Beam SP-751 Alloy, diameter 31.6mm, length 300mm, micro-adjustment
Saddle

SDG I-Fly 2.0 I-Beam, high-density PU foam, Cordura sides

Front brake

Sram Code R, oversized 4-piston caliper, Centerline 220mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads
Rear brake

Sram Code R, oversized 4-piston caliper, Centerline 203mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads

Brake lever

Sram Code R, tool-free reach adjust
Rims

e*thirteen LG1 Plus DH, IW29 29" Hookless, 6069 Welded Aluminum, 30mm internal width, tubeless ready, 32 spokes

Spokes

e*thirteen custom Hive triple-butted black steel, alloy nipples, nipple washers
Front hub

e*thirteen Boost 20x110mm, triple-sealed, fully machined aluminum, IS 6 bolts

Rear hub

e*thirteen Superboost 12x157mm, triple-sealed, fully machined aluminum w/6-degree engagement, IS 6 bolts
Front tire

Michelin DH34 29x2.4, tubeless ready, Magi-X DH compound, double-reinforced DH shield casing, wire bead

Rear tire

Michelin DH34 29x2.4, tubeless ready, Magi-X DH compound, double-reinforced DH shield casing, wire bead
Crankset

Truvativ Descendant DH, DUB axle, Direct mount chain ring, 165mm

Rings

34T, steel, X-SYNC
Bottom bracket

Sram DUB BSA, sealed bearings, 83mm

Chain

Sram PC1110 11s, Powerlock
Front derrailleur

E.13 Vario Compact Upper Slider ,Alloy backplate ,DMB (Direct mount Bashguard) Lower Slider 34-36t, ISCG 05 adjustable upper slider

Rear derrailleur

Sram GX DH, 7s, medium cage, X-actuation 1:1
Shift levers

Sram trigger GX DH 7s, X-actuation 1:1

Casette

Sram PG 720 11-25T, 7s

Others

*Optional geometry kit: +-1º / +-2º headset cups

Weight

16,9 kg

Geometry

Frame size		S	M	L
A	Seattube length	400 mm	400 mm	400 mm	400 mm
B	Toptube length	575 mm	595 mm	620 mm	645 mm
C	Bottom bracket drop	-20 mm	-20 mm	-20 mm	-20 mm
D	Bottom bracket height	350 mm	350 mm	350 mm	350 mm
E	Chainstay length	450/455/460 mm	450/455/460 mm	450/455/460 mm	450/455/460 mm
F	Seat tube angle	69°	68.5º	69°	69°
G	Effective seattube angle	77°	77°	77°	77°
H	Headtube angle	63º	63,5º	63,5º	63,5º
I	Fork Offset	56 mm	56 mm	56 mm	56 mm
J	Wheelbase	1260 mm	1270 mm	1295 mm	1320 mm
K	Headtube length	110 mm	110 mm	112 mm	112 mm
L	Reach	430 mm	450 mm	475 mm	500 mm
M	Stack	632 mm	633 mm	632 mm	632 mm

Mondraker

2025 Mondraker Crafty Race EMTB

£5,799.00

Tax included. Shipping calculated at checkout.

CRAFTY

THE GAME IS OVER!

The game is over, welcome to a new generation of authentic e-Enduro. Without compromises, the new Crafty Race is a pure performance model, an authentic Enduro bike; With great suspension capability and amazing pedaling efficiency ... agile like no other 29” e-MTB thanks to its renewed Forward Geometry and, all sweetened with raw power of the fourth generation of the Bosch CX Race Motor system. Enjoy the real life.

Components

Technical specs

Frame

Crafty 6061 Alloy Stealth Evo, e-Bike Optimized Zero Suspension System, 150mm travel, Forward Geometry, internal non-removable battery, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 17mm axles, integrated dropout speed sensor, exclusive plastic motor covers.

Sizes

S: 380mm / M: 420mm / L: 450mm / XL: 490mm
Rear shock

Fox Float-X LV Performance, 205x65mm. Settings: compression 2 positions lever, low-speed rebound, air preload. Trunnion top mount, 25x10mm bottom bushings

Shock settings

medium compression, medium rebound, air volume spacer 0.2
Fork

Fox 38 29 Float FIT GRIP EVOL Performance, 160mm, e-bike tuned, tapered steerer tube, Boost 15x110mm axle, 44mm offset. Settings: 3 positions with micro adjust compression, low-speed rebound, air preload

Headset

Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º
Stem

Onoff Sulfur FG 30mm 0º, 6061 forged alloy, 31.8mm barbore

Handlebar

Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore
Grips

Onoff Desert, 1lock-on, 135mm

Seatpost

Onoff Pija dropper internal, diameter 31.6mm, 1X Remote lever with bearing, S size: 405x95-125mm, M size: 458x120-150mm, L size: 498x140-170mm, XL size: 558x170-200mm
Saddle

Ergon SM-10

Front brake

Shimano XT M8120, 4 piston caliper, MT800 ICE-Tech 203mm CenterLock rotor, resin pads with fin
Rear brake

Shimano XT M8120, 4 piston caliper, MT800 ICE-Tech 203mm CenterLock rotor, resin pads with fin

Brake lever

Shimano XT M8100, ergonomic antiskid lever with servo wave, tool less reach adjust, free stroke adjust
Rims

Mavic E-Deemax 29, 30mm internal width, welded, PFP, tubeless ready, 28 spokes

Spokes

Mavic J-bend double butted, contactless lacing
Front hub

Mavic, Boost 15x110mm, IS 6 bolts

Rear hub

Mavic, Boost 12x148mm, ID360 Ratched system, IS 6 bolts, MS freehub
Front tire

Maxxis Minion DHF 29x2.6, tubeless ready, 3C MAXX TERRA, EXO+ Protection, 120TPI, folding bead

Rear tire

Maxxis Minion DHR II 29x2.6, tubeless ready, 3C MAXX TERRA, EXO+ Protection, 120TPI, folding bead
Crankset

Race Face Aeffect-R ebike, 160mm

Rings

Race Face, 34T, steel, direct mount
Chain

Shimano XT M8100, 12s

Rear derrailleur

Shimano XT M8100, SGS, Shadow+
Shift levers

Shimano XT M8100, Rapid Fire Plus, 12s

Casette

Shimano XT M8100 10-51T Hyperglide+, 12s
Derailleur hanger

Mondraker M068

Weight

25,2 kg
Display

Purion 400 Bosch Mini Remote / Bosch System Controller

Motor

Bosch Performance Line CX-Race (25Km/h) GEN4 SMART SYSTEM

Battery

Bosch Powertube 750Wh

Geometry


	Frame size	S	M	L	XL
A	Seattube length	380mm	420mm	450mm	490mm
B	Toptube length	605mm	625mm	650mm	670mm
C	Bottom bracket drop	-25mm	-25mm	-25mm	-25mm
D	Bottom bracket height	350mm	350mm	350mm	350mm
E	Chainstay length	455mm	455mm	455mm	455mm
F	Seat tube angle	73.5°	73.5°	73.5°	73.5°
G	Effective seattube angle	76°	76°	76°	76°
H	Headtube angle	65.5°	65.5°	65.5°	65.5°
I	Fork Offset	44mm	44mm	44mm	44mm
J	Wheelbase	1225mm	1245mm	1265mm	1285mm
K	Headtube length	110mm	110mm	130mm	130mm
L	Reach	450mm	470mm	490mm	510mm
M	Stack	622mm	622mm	640mm	640mm

Mondraker

2025 Mondraker Sly R EMTB

£5,299.00

Tax included. Shipping calculated at checkout.

IT’S ABOUT WHO YOU WANT TO BE

SLY belongs to each and every one of us. To you too. A new breed of ebike blending Stealth aluminium with a Bosch SX motor and a 400Wh battery. Providing a balanced power delivery to make you the master of your rides. It’s not about who you are when you’re riding an ebike. It’s about who you want to be. Introducing SLY. ONE SLY FITS ALL.

R AND RR: TWO BUILDS THAT DEFINE SLY

Sometimes less is more. We had that clear from the beginning when designing SLY. The two builds available are the R and the RR, and they both boast 4 piston brakes, all-new 2.5” Maxxis DHF/DHR II EXO+ tyres, 12 speed Eagle T-Type drivetrains, up to 210mm ONOFF Pija dropper posts, and 800mm handlebars. The R build comes with a 160mm fork with 35mm stanchions, while the RR has a burlier 160mm fork with 36mm stanchions. Both models come with the Bosch display, mounted on the handlebar. And the mini remote on the handlebar to switch between assist modes on the Bosch SX motor.

SLY R: ACCESS YOUR SLY

Access a world of SLY. Access the best cost performance out there.

The R build offers RockShox suspension with a Psylo Gold RC 160mm fork paired with a Rockshox Deluxe Select+ shock; SRAM 4 piston DB8 Stealth brakes to keep things firmly under control, and Mavic 29”, 30mm E-CrossRide 29 wheels for reliability and strength.

Our component brand ONOFF supplies the handlebar, grips and stem from its S3 range, while the S6 range offers up the Pija seatpost in lengths from 140mm to 210mm depending on frame size.

The SLY R comes in the spectacular Marlin Blue / Racing Silver / Obsidian Grey colourway.

Technical Specifications

Frame

6061 Alloy Stealth Evo, hydroformed tubing, Updated Zero Suspension System, 150mm travel, Forward Geometry, internal battery, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 15mm axles, exclusive plastic motor covers.

Sizes

S: 380mm / M: 410mm / ML: 435mm / L: 460mm / XL: 490mm
Rear shock

Rockshox Deluxe Select+, 185x55mm, Trunnion top mount, 30x8mm bottom bushings

Shock settings

L compression, digressive rebound, 4 tokens
Fork

Rockshox Psylo Gold RC, 160mm, 3 Position, Debon Air, tapered steerer tube, Boost 15x110mm axle, 35mm steel stanchions, 44mm offset. Settings: compression adjustment at low-speed to lock, rebound, air preload

Headset

Acros custom IS52/ZS56, 1-1/8", 1.5" head tube, Internal cable routing, sealing plugs without blocklock
Stem

Onoff S3 30mm 0º, 6061 forged alloy, 31.8mm barbore

Handlebar

Onoff S3 1.0 6061 alloy, rise: 25mm, width: 800mm, 8º backsweep, 5º upsweep, 31.8mm barbore. L and XL size: 1.5 rise.
Grips

Onoff Forest, CNC lock-on, 135mm

Seatpost

Onoff Pija dropper internal, diameter 31.6mm, 1X Remote lever with bearing, S size: 140-115mm (388-235mm), M size: 160-135mm (428-255mm), ML size: 180-155mm (468-275mm), L size: 210-185mm (528-305mm), XL size: 210-185mm (528-305mm)
Saddle

Fizik Terra Aidon X5 145mm

Front brake

Sram DB8 stealth, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads
Rear brake

Sram DB8 stealth, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads

Brake lever

Sram DB8, SwingLink and lever pivot bearings, tools-free reach and contact point adjust
Rims

Mavic E-CrossRide 29, 30mm internal width, welded, PFP, tubeless ready, 28 spokes

Spokes

Mavic J-bend double butted, contactless lacing
Front hub

Mavic, Boost 15x110mm, IS 6 bolts

Rear hub

Mavic, Boost 12x148mm, ID360 Ratched system, IS 6 bolts, HG freehub
Front tire

Maxxis Minion DHF 29x2.5 WT, tubeless ready, 3C MAXX GRIP compound, EXO+ protection, 60TPI, folding bead

Rear tire

Maxxis Minion DHR II 29x2.5 WT, tubeless ready, 3C MAXX TERRA compound, EXO+ protection, 60TPI, folding bead
Crankset

e*Thirteen Helix Core E*Spec Plus, All sizes: 160mm

Rings

Sram X-Sync 2 Eagle 34T, steel, narrow-wide, 104 BCD
Chain

Sram GX Eagle T-Type, 12s, Powerlock

Rear derrailleur

Sram S1000 Eagle AXS T-Type, 12s
Shift levers

Sram Eagle AXS Pod MMX, 12s

Casette

Sram XS-1270, 10-52T, T-Type, 12s
Weight

20,9 kg

Display

Purion 400 / Bosch Mini Remote / Bosch System Controller

Motor

Bosch Performance Line SX (25Km/h) GEN4 SMART SYSTEM Diagonal, Wide

Battery

Bosch Compact Powertube 400Wh

Geometry

Frame size		S	M	M/L	L
A	Seattube length	380 mm	410 mm	435 mm	460 mm	490 mm
B	Toptube length	595 mm	615 mm	635 mm	660 mm	685 mm
C	Bottom bracket drop	-22 mm	-22 mm	-22 mm	-22 mm	-22 mm
D	Bottom bracket height	350 mm	350 mm	350 mm	350 mm	350 mm
E	Chainstay length	455 mm	455 mm	455 mm	455 mm	455 mm
F	Seat tube angle	74º	74º	74º	74º	74º
G	Effective seattube angle	77º	77º	77º	77º	77º
H	Headtube angle	64,5º	64,5º	64.5º	64,5º	64,5º
I	Fork Offset	44 mm	44 mm	44 mm	44 mm	44 mm
J	Wheelbase	1225 mm	1250 mm	1265 mm	1290 mm	1315 mm
K	Headtube length	120 mm	120 mm	130 mm	140 mm	150 mm
L	Reach	440 mm	460 mm	480 mm	500 mm	520 mm
M	Stack	633 mm	633 mm	642 mm	651 mm	660 m

Mondraker

2025 Mondraker Trick 24

£1,349.00 £1,199.00 Save £150.00

Tax included. Shipping calculated at checkout.

START YOUR MONDRAKER JOURNEY WITH TRICK

You never forget the first time you rode a bike, just like you’ll never forget that first time you rode a Mondraker. That feeling you got from those first pedal strokes is indelible. The new Trick range, available in 16”, 20”, 24” and 26” sizes, will start a relationship with Mondraker that we’re sure will last you a lifetime.

ADULT TECH TO MAKE YOU FEEL LIKE A KID

The new Trick rewrites everything compared to the old Leader, as this year brings a fresh new frame design with a design language clearly influenced by our high-end adult bikes. Minimalistic frame tubes, straighter lines, and details such as the top tube flowing into the seat stays in an almost straight line, and nothing says ‘Mondraker’ more than the ‘window’ between the top tube, the down tube and the headtube now featured on the Trick too.

Components

Technical specs

Frame

Trick 24 6061 Alloy Stealth Evo, HHG internal cable routing, internal headset, replaceable hanger, BSA bottom bracket, 12x142mm rear axle

Sizes

One size 310mm
Fork

X-Fusion Velvet RL 26, 100mm, air spring, tapered steerer tube, 15x100mm axle, 32mm aluminum stanchions, 41mm offset. Settings: lockout, rebound, air preload

Headset

FPD Dozer tapered internal 1048AS, 1-1/8" 1-1/2 15mm top cover + TJ3 top cap
Stem

MDK XC, 6061 forged alloy, 25.4mm barbore, rise: 0º, length: 40mm

Handlebar

MDK XC 1.0, 6061 alloy, rise: 25mm, width: 650mm, 9º backsweep, 5º upsweep, 31.8mm barbore
Grips

Onoff Twin, 1lock-on

Seatpost

MDK XC, 6061 T6 alloy, diameter 31.6mm, length 300mm, offset 0mm
Saddle

SDG Fly JR

Front brake

Sram Level, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad
Rear brake

Sram Level, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad

Brake lever

Sram Level, tooled reach adjust, lever pivot bushings
Rims

MDK-XP1 24 TLR, 25mm internal width, tubeless ready, 32 spokes

Spokes

CN round stainless steel
Front hub

DA210FS02, 15x100mm, sealed bearings, IS 6 bolts

Rear hub

DA210RSRA01 12x142mm, sealed bearings, IS 6 bolts, HG freehub
Front tire

Kenda Booster 24x2.4 single compound 30TPI, wire bead

Rear tire

Kenda Booster 24x2.4 single compound 30TPI, wire bead
Crankset

Samox DM 30T steel, 127mm

Rings

30T, steel
Bottom bracket

BSA, 73mm

Pedals

SDG Slater JR
Chain

Sram PC-1031, 10s, Powerlock

Rear derrailleur

MICROSHIFT ADVENT X-RDM6205GM 1X10
Shift levers

MICROSHIFT ADVENT SL-M9505-R 10s

Casette

MICROSHIFT CS-G104 11-48 BLACK

Derailleur hanger

UDH

Weight

11,7 kg

Geometry


	Frame size	Trick 24
A	Seattube length	310mm
B	Toptube length	510mm
C	Bottom bracket drop	-30mm
D	Bottom bracket height	285mm
E	Chainstay length	385mm
F	Seat tube angle	73º
G	Effective seattube angle	73º
H	Headtube angle	68º
I	Fork Offset	40mm
J	Wheelbase	979mm
K	Headtube length	100mm
L	Reach	341mm
M	Stack	553mm

Ex-Demo 2024 Mondraker Summum R Mullet Alloy Downhill Bike Small

Mondraker

Ex-Demo 2024 Mondraker Summum R Mullet Alloy Downhill Bike Small

£3,499.00 £3,100.00 Save £399.00

Tax included. Shipping calculated at checkout.

Ex-Demo 2024 Mondraker Summum R Alloy DH bike - Size Small

Frame	Summum Mullet 6061 Alloy Stealth Evo, hydroformed tubing, Zero suspension system, 200mm travel, Forward Geometry, alloy upper link with shock eyelet bearings, SuperBoost 12x157mm rear axle, MAX. capacity dual row Enduro bearings
Fork	Fox 40 29 Float FIT GRIP EVOL Performance, 203mm, air spring, 1-1/8” steerer tube, 20x110mm axle, offset 56mm. Settings: low-speed compression, low-speed rebound, air preload
Rear Shock	Fox DHX2 Performance Elite, 225x70mm. Settings: low-speed compression, low-speed rebound, spring preload. Trunnion top mount, 30x8mm bottom bushings
Headset	ONOFF Mercurium 1.5 ZS for 1-1/8” steerer tube, 41x30.15x7x45ºx45º ACB sealed bearings, geometry kit cups, external diameter 56mm
Stem	ONOFF Krypton DH CNC Integrated FG, 25-30mm adjustable length, 31.8mm barbore, 6061 alloy, 2x6mm spacer
Bars	ONOFF Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore
Front Brake	Sram Code R, oversized 4-piston caliper, Centerline 220mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads
Rear Brake	Sram Code R, oversized 4-piston caliper, Centerline 203mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads
Brake Lever	SRAM Code R, tool-free reach adjust
Front Mech	E.13 Vario Compact Upper Slider ,Alloy backplate ,DMB (Direct mount Bashguard) Lower Slider 34-36t, ISCG 05 adjustable upper slider
Rear Mech	SRAM GX DH, 7s, medium cage, X-actuation 1:1
Shifters	SRAM trigger GX DH 7s, X-actuation 1:1
Speed	7
Rims	e*thirteen LG1 Plus DH, IW29 29"/27.5" Hookless, 6069 Welded Aluminum, 30mm internal width, tubeless ready, 32 spokes
Front Hub	e*thirteen Boost 20x110mm, triple-sealed, fully machined aluminum, IS 6 bolts
Rear Hub	e*thirteen Superboost 12x157mm, triple-sealed, fully machined aluminum w/6-degree engagement, IS 6 bolts
Spokes	e*thirteen custom Hive triple-butted black steel, alloy nipples, nipple washers
Front Tyre	Michelin DH34 29x2.4, tubeless ready, Magi-X DH compound, double-reinforced DH shield casing, wire bead
Rear Tyre	Michelin DH34 27.5x2.4, tubeless ready, Magi-X DH compound, double-reinforced DH shield casing, wire bead
Seat Post	SDG Micro I-Beam SP-751 Alloy, diameter 31.6mm, length 300mm, micro-adjustment
Saddle	SDG I-Fly 2.0 I-Beam, high-density PU foam, Cordura sides
Chainset	Truvativ Descendant DH, DUB axle, Direct mount chain ring, 165mm. 34T, steel, X-SYNC
Bottom Bracket	SRAM DUB BSA, sealed bearings, 83mm
Chain	SRAM PC1110 11s, Powerlock
Cassette	SRAM PG 720 11-25T, 7s
Pedals	None

Mondraker

Mondraker Chrono 29 Alloy

£1,199.00 £839.00 Save £360.00

Tax included. Shipping calculated at checkout.

THE CHRONO, BEFORE ALL ELSE, IS A DYNAMIC BIKE

The CHRONO, before all else, is a dynamic bike. Its butted 6061 Xtralite aluminium frame has our XC FORWARD GEOMETRY which puts you in an optimal position for pedaling efficiency while offering greater safety and confidence when facing descents. It’s the first bike on price that lets you get to enjoy our more than 20 years of knowledge in the manufacture of top class bikes, because we want you to be able enjoy our purest Racing DNA whatever your budget.

Frame

Chrono 29 Stealth Alloy, XC Forward Geometry, 73mm BSA bottom bracket, tapered head tube, HHG Internal Cable Routing, Boost 12x148mm rear axle

Sizes

S: 395mm / M: 430mm / L: 470mm / XL: 520mm
Fork

RockShox Judy Silver TK 29, 100mm, TurnKey, Solo Air, tapered steerer tube, 9x100mm axle, 30mm steel stanchions, 46mm offset. Settings: Poplock 2 pos remote compression (open/lock), rebound, air preload

Fork remote

RockShox PopLoc
Headset

ONOFF Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º

Stem

ONOFF Sulfur, 6061 T6 Alloy, 31.8mm barbore, rise: +/-7º, length: sizes S/M: 60mm, size L: 80mm, size XL: 90mm
Handlebar

ONOFF Sulfur 0.2, double butted 6061 alloy, rise: 4.8mm, width: 740mm, 9º backsweep, 0º upsweep, 31.8mm barbore

Grips

ONOFF Twin, 1lock-on, 135mm
Seatpost

ONOFF Sulfur 0-R, 6061 T6 Alloy, 3D forged, diameter 27.2mm, length 400mm

Saddle

Mondraker XC Series, steel rail
Front brake

Sram Level, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad

Rear brake

Sram Level, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad
Brake lever

Sram Level, tooled reach adjust, lever pivot bushings

Rims

MDK-XP1 29 TLR, 25mm internal width, tubeless ready, 32 spokes
Spokes

CN round stainless steel

Front hub

Formula DC20LW, 9x100mm, cup & cone ball bearings, IS 6 bolts
Rear hub

Formula MST148S-4SB, Boost 12x148mm, sealed bearings, IS 6 bolts, MS freehub

Front tire

Maxxis Ikon 29x2.20, 60TPI, wire bead
Rear tire

Maxxis Ikon 29x2.20, 60TPI, wire bead

Crankset

Sram SX Eagle, Boost, DUB axle, Direct Mount chain ring, S size: 170mm, M/L/XL size: 175mm
Rings

34T, steel, X-Sync 2

Bottom bracket

Sram DUB BSA, sealed bearings, 73mm
Chain

Sram SX Eagle, 12s, Powerlock

Rear derrailleur

Sram SX Eagle, Type 3 roller bearing clutch, cage lock, long cage, 1x12s, X-actuation 1:1
Shift levers

Sram Trigger SX Eagle, 12s, X-Actuation 1:1

Casette

Sram PG-1210, 11-50T, 12s

Derailleur hanger

Mondraker M068

Weight

12,9 kg

FRAME SIZE		S	M	L
A	Seattube length	395mm	430mm	470mm	520mm
B	Toptube length	590mm	610mm	630mm	650mm
C	Bottom bracket drop	-65mm	-65mm	-65mm	-65mm
D	Bottom bracket height	305mm	305mm	305mm	305mm
E	Chainstay length	435mm	430mm	435mm	435mm
F	Seat tube angle	72.5°	72.5°	72.5°	72.5°
G	Effective seattube angle	73.5°	73.5°	73.5°	73.5°
H	Headtube angle	70°	70°	70°	70°
I	Fork Offset	44/46mm	44/46mm	44/46mm	44/46mm
J	Wheelbase	1087mm	1107mm	1127mm	1148mm
K	Headtube length	100mm	100mm	110mm	125mm
L	Reach	406mm	426mm	444mm	460mm
M	Stack	618mm	618mm	628mm	642mm

Mondraker

Mondraker Crafty RR E-MTB

£6,499.00 £4,499.00 Save £2,000.00

Tax included. Shipping calculated at checkout.

Taking full advantage of its optimized ZERO suspension system this bike soaks up the trail chatter like a dream. Then you add FORWARD GEOMETRY and a STEALTH ALLOY EVO frame to give you spectacular agility and the most fun ride you can imagine. The Fox 38 fork together with Fox’s Float X shock absorber, both from the Factory range, provide mind-blowing control whatever the situation and however gnarly things get. There’s no question the improvements to the CRAFTY RR will make you feel like a pro.

TECHNICAL SPECS

Frame

Crafty 6061 Alloy Stealth Evo, e-Bike Optimized Zero Suspension System, 150mm travel, Forward Geometry, internal non-removable battery, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 17mm axles, integrated dropout speed sensor, exclusive plastic motor covers.

Sizes

S: 380mm / M: 420mm / L: 450mm / XL: 490mm
Rear shock

Fox Float-X LV Factory Kashima, 205x65mm. Settings: compression 2 positions lever, low-speed compression, low-speed rebound, air preload. Trunnion top mount, 25x10mm bottom bushings

Shock settings

medium compression, medium rebound, air volume spacer 0.2
Fork

Fox 38 29 Float GRIP2 Factory Kashima, 160mm, e-bike tuned, tapered steerer tube, Boost 15x110mm axle, offset 44mm. Settings: high and low-speed compression, high and low-speed rebound, air preload

Headset

Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º
Stem

Onoff Sulfur FG 30mm 0º, 6061 forged alloy, 31.8mm barbore

Handlebar

Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore
Grips

Onoff Desert, 1lock-on, 135mm

Seatpost

Fox Transfer Factory Kashima internal, diameter 31.6mm, S size: 363.5x125mm, M size: 418.3x150mm, L/XL size: 475.1x175mm
Saddle

FIZIK Terra Aidon X5 145mm

Front brake

Sram Code R, oversized 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads
Rear brake

Sram Code R, oversized 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads

Brake lever

Sram Code R, tool-free reach adjust
Rims

Mavic E-Deemax 29, 30mm internal width, welded, PFP, tubeless ready, 28 spokes

Spokes

Mavic J-bend double butted, contactless lacing
Front hub

Mavic, Boost 15x110mm, IS 6 bolts

Rear hub

Mavic, Boost 12x148mm, ID360 Ratchet system, IS 6 bolts
Front tire

Maxxis Minion DHF 29x2.6, tubeless ready, 3C MAXX TERRA, EXO+ Protection, 120TPI, folding bead

Rear tire

Maxxis Minion DHR II 29x2.6, tubeless ready, 3C MAXX TERRA, EXO+ Protection, 120TPI, folding bead
Crankset

Race Face Aeffect ebike, 165mm

Rings

Sram X-Sync 2 Eagle 34T, steel, narrow-wide, 104 BCD
Chain

Sram NX Eagle, 12s, Powerlock

Rear derrailleur

Sram GX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1
Shift levers

Sram Trigger GX Eagle, 12s, X-Actuation 1:1, single click

Casette

Sram XG-1230, 11-50T, 12s
Derailleur hanger

Mondraker M068

Weight

25,5 kg
Display

Bosch Kiox 300 / Bosch Mini Remote / Bosch System Controller

Motor

Bosch Performance Line CX (25km/h) Smart System

Battery

Bosch Powertube 750Wh

GEOMETRY

FRAME SIZE	S	M	L	XL
A	Seattube length	380mm	420mm	450mm	490mm
B	Toptube length	605mm	625mm	650mm	670mm
C	Bottom bracket drop	-25mm	-25mm	-25mm	-25mm
D	Bottom bracket height	350mm	350mm	350mm	350mm
E	Chainstay length	455mm	455mm	455mm	455mm
F	Seat tube angle	73.5°	73.5°	73.5°	73.5°
G	Effective seattube angle	76°	76°	76°	76°
H	Headtube angle	65.5°	65.5°	65.5°	65.5°
I	Fork Offset	44mm	44mm	44mm	44mm
J	Wheelbase	1225mm	1245mm	1265mm	1285mm
K	Headtube length	110mm	110mm	130mm	130mm
L	Reach	450mm	470mm	490mm	510mm
M	Stack	622mm	622mm	640mm	640mm

Mondraker

Mondraker Element Jacket

£99.95 £69.95 Save £30.00

Tax included. Shipping calculated at checkout.

Properties: Windproof | Rainproof
Fit: Men's | Perfect fit
Temperature of Use: +5 to +15 ºcMain fabric
100% Nylon 'Ripstop' fabric
DWR (Durable Water Repellent) Water Repellent
Lightweight, breathability and tear resistance.
Waterproof DWR treatment.
Reflective back.

Mondraker

Mondraker Enduro Jersey Forest Green

£74.95

Tax included. Shipping calculated at checkout.

Mondraker

Mondraker Forest Air MTB Jersey

£63.95 £39.00 Save £24.95

Tax included. Shipping calculated at checkout.

•Main fabric: 100% Polyester

•Moisture-wicking and abrasion-resistant fabric

•Designed construction for an absolute comfort and a perfect fittment

Mondraker

Mondraker Halftone T-Shirt

£24.95

Tax included. Shipping calculated at checkout.

The Mondraker t-shirt is comfortable, versatile and is perfect for a casual bike ride or for spending the day maintaining your rider image that you love so much.

Mondraker

Mondraker Navy Condensed T Shirt

£24.95

Tax included. Shipping calculated at checkout.

Premium high-density cotton, 180gr/m2
Straight cut, designed to allow natural movement
Textile label with the Mondraker logo
High quality round neck

Mondraker

Mondraker Neat R Light EMTB

£6,795.00 £4,499.00 Save £2,296.00

Tax included. Shipping calculated at checkout.

PLEASE EVERYONE, STAND UP AND WELCOME THE NEAT.

A new beginning. A new era of ebikes. Born and bred with all of our character, identity and feeling. A Mondraker by definition, but more manoeuverable, nimble and even faster than ever before. A new cycle with a new leader.

A NEW CYCLE

Three years ago, we started a project with a mission. Just one. To create a new generation of ebikes that would redefine the current concept of mountain biking. A new category which would enhance the very best version of yourself as a rider, to make you faster, everywhere. Powerful yet silent. Stable yet agile. A mission we dubbed NEAT and which has led to the first Light e-MTB in our history. With this model we’re opening the doors to a new category with the TQ-HPR50 motor, an integrated removable 360W battery, a full carbon fibre frame and a ready to roll weight of under 18kg. Mission accomplished. Now it’s your turn. Mondraker NEAT.

The NEAT range shares the same carbon fibre frame but with three different builds to choose from: NEAT R, NEAT RR and NEAT RR SL. All three come with a Fox Float X shock and Fox 36 fork, 4 piston brakes and Maxxis Minion DHF and DHR tyres with EXO+ sidewalls.

The package is completed with an ebike specific wheel and tyre package, 4 piston brakes and the quietest and most advanced motor on the market: the TQ-HPR50, combined with an integrated removable 360Wh battery. We didn’t rush this project, but the results speak for themselves: The NEAT is here. The NEAT is a reality.

NEAT R

The first model in the line-up is the NEAT R, with a Fox 36 29 Float GRIP EVOL Performance fork, SRAM GX Eagle transmission, SRAM G2 R brakes, ONOFF Pija seatpost of up to 200mm travel (depending on size) and Mavic E-Crossride 29 wheels.

Frame

Stealth Air full Carbon, e-Bike Optimized Zero Suspension System, 150mm travel, Forward Geometry, internal & removable battery, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 15mm axles, integrated dropout speed sensor, exclusive plastic motor covers.

Sizes

S: 380mm / M: 420mm / L: 450mm / XL: 490mm
Rear shock

Fox Float X Performance EVOL, 185x55mm. Settings: 2-position compression (Open/Firm), rebound, air preload. Trunnion top mount, 30x8mm bottom bushings

Shock settings

Medium compression, medium rebound, air volume spacer 0.4
Fork

Fox 36 29 Float GRIP EVOL Performance, 160mm, tapered steerer tube, Boost 15x110mm axle, 44mm offset. Settings: 3 positions with micro adjust compression, low-speed rebound, air preload

Headset

Acros custom for 1-1/2" head tube, angular contact bearings 40x52x7, Internal cable routing
Stem

Onoff Krypton FG 30mm, CNC, 31.8mm barbore

Handlebar

Onoff Krypton 1.0, rise: 25mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore
Grips

Onoff Desert, 1lock-on, 135mm

Seatpost

Onoff Pija dropper internal, diameter 31.6mm, 1X Remote lever with bearing, S size: 405x95-125mm, M size: 458x120-150mm, L size: 498x140-170mm, XL size: 558x170-200mm
Saddle

Fizik Terra Aidon Slim X5

Front brake

Sram G2 R, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads
Rear brake

Sram G2 R, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads

Brake lever

Sram G2 R, tool-free reach adjust, lever pivot bushings
Rims

Mavic E-CrossRide 29, 30mm internal width, welded, PFP, tubeless ready, 28 spokes

Spokes

Mavic J-bend double butted, contactless lacing
Front hub

Mavic, Boost 15x110mm, IS 6 bolts

Rear hub

Mavic, Boost 12x148mm, ID360 Ratched system, IS 6 bolts, HG freehub
Front tire

Maxxis Minion DHF 29x2.5 WT, tubeless ready, 3C MAXX TERRA compound, EXO+ protection, 120TPI, folding bead

Rear tire

Maxxis Minion DHR II 29x2.4 WT, tubeless ready, 3C MAXX TERRA compound, EXO+ protection, 120TPI, folding bead
Crankset

E.13 E*Spec Plus,, S size: 165mm M size: 165mm L size: 170mm XL size: 170mm

Rings

Sram X-Sync 2 Eagle 34T, steel, narrow-wide, 104 BCD
Chain

Sram NX Eagle, 12s, Powerlock

Rear derrailleur

Sram GX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1
Shift levers

Sram Trigger NX Eagle, 12s, X-Actuation 1:1, single click

Casette

Sram PG-1230, 11-50T, 12s
Derailleur hanger

Sram UDH

Others

Mondraker custom desing Fidlock smoked transparent 600ml bottle + Fidlock base down version *Optional external battery: TQ 160Wh
Weight

18.9 kg - Max System Weight 150kg.

Display

TQ HPR display V01
Motor

TQ HPR-50

Battery

TQ HPR-50 360Wh integrated and removable

After several years of taking stock of the state of the market and deciding that it just didn’t convince us, we developed the NEAT project utilizing an innovative system of motor and battery, more than capable of satisfying the needs of this sector and with which we felt we could identify as riders. We understood that weight was a key factor for this new platform, but we couldn’t let it compromise the performance of the whole package, the suspension travel or the handling.

BEST OF BOTH WORLDS

Mondraker has managed to merge the best of both worlds by blending our two category leading bikes: the Enduro FOXY CARBON and e-MTB Enduro CRAFTY CARBON. 2024 then, sees the arrival of NEAT. A model with unmistakable aesthetics, characteristics and identity which sets a benchmark in this new category.

DEFINING OUR LIGHT E-MTB

NEAT is our vision of what the Light e-MTB category should be, while bringing the character which defines all Mondraker bikes into the mix.

NEAT is the product of our desire to blur the line between traditional MTBs and full power eMTBs, creating a bike which truly offers the best of both worlds. A 150mm enduro bike with a 160mm fork, the lower limit travel for maximum performance. Light, but without sacrificing anything in the process.

LIGHT WEIGHT WITHOUT COMPROMISE

NEAT is the expression of a new design concept. The layout is more angular, cleaner, especially around the headtube. This area, where the headtube joins both the top tube and the down tube, defines the identity of all Mondrakers, and expresses from this model on a new look for the brand.

The defining lightness of the frame (only 2300 grams) together with the redesigned swingarm which is lighter and more compact, make NEAT the lightest ever MTB ebike in the history of Mondraker, weighing in at under 18kg for the RR SL build.

THE BALANCED GEOMETRY OF NEAT

NEAT comes with category specific geometry and counts on the best that the FOXY CARBON and CRAFTY CARBON offer in their respective categories.

64.5º head angle. As slack as a FOXY CARBON in the LOW setting.

76.5º effective seat tube angle. 1º steeper than the FOXY CARBON.

450mm chainstays. 5mm shorter than the CRAFTY CARBON and 5mm longer than the FOXY CARBON.

BB height of 348mm (-25mm drop). The perfect height for an ebike of its class.

Reach of 450/470/495/515mm (S/M/L & XL). Reach figures inspired by the FOXY CARBON and CRAFTY CARBON.

FRAME SIZE		S	M	L
A	Seattube length	380mm	420mm	450mm	490mm
B	Toptube length	595mm	615mm	640mm	660mm
C	Bottom bracket drop	-25mm	-25mm	-25mm	-25mm
D	Bottom bracket height	348mm	348mm	348mm	348mm
E	Chainstay length	450mm	450mm	450mm	450mm
F	Seat tube angle	72,6º	72,6º	72,6º	72,6º
G	Effective seattube angle	76.5°	76.5°	76.5°	76.5°
H	Headtube angle	64.5º	64.5º	64.5º	64.5º
I	Fork Offset	44mm	44mm	44mm	44mm
J	Wheelbase	1235mm	1255mm	1275mm	1295mm
K	Headtube length	110mm	110mm	130mm	140mm
L	Reach	450mm	470mm	495mm	515mm
M	Stack	626mm	626mm	642mm	650 mm

NATURAL FEEL TQ-HPR50 SYSTEM

The TQ-HPR50 system comprises a very compact motor which we’ll talk about later on, a 360Wh removable internal battery located in the downtube, a 2” display fitted into the top tube and an optional 160Wh range extender. The whole system weighs in at 3.9Kg, 1850g the motor and 1830g the 360Wh battery. The optional TQ range extender weighs 950g.

Combining 3 natural-feeling levels of assistance and running almost silently, the TQ-HPR50 provides up to 300W of power and 50Nm of torque. A multitude of variables will always come into play when talking about range, but a rider of average weight (around 75Kg) can expect to be able to complete a ride of between 3-4 hours, with more than 1000m of altitude gain, switching between ECO and MID modes, and ride anywhere from 40 to 50km. The optional range extender can increase that by up to 50%.

NEAT = ANY TYPE OF RIDER AND ANY TYPE OF RIDING

NEAT is a new category of bike for Mondraker. A category that was until now unrealised, falling between the flexibility of a FOXY CARBON and the capability of a CRAFTY CARBON. NEAT walks the perfect line between the two, for any type of rider and any type of riding.

-Riders who are making the move from a traditional mountain bike or who are just starting out on an ebike: NEAT lets you ride faster, farther, and descend with more aplomb and more safely than ever before, without sacrificing the feelings and handling of a traditional non-ebike MTB.

-Riders who are making the move from a full power ebike: NEAT is going to make your ride fleeter of foot, more agile, and faster reacting on climbs without giving up the traits of an ebike on the descents.

Geometry

PERFECT FOR RIDERS WHO WANT A BIKE THAT OFFERS THE WHOLE PACKAGE AT A REASONABLE PRICE

TECHNICAL SPECS

The SUMMUM CARBON R inherits all of the features from the CARBON RR

Technical specs

CRAFTY

THE GAME IS OVER!

Technical specs

IT’S ABOUT WHO YOU WANT TO BE

R AND RR: TWO BUILDS THAT DEFINE SLY

START YOUR MONDRAKER JOURNEY WITH TRICK

Technical specs

THE CHRONO, BEFORE ALL ELSE, IS A DYNAMIC BIKE

TECHNICAL SPECS

PLEASE EVERYONE, STAND UP AND WELCOME THE NEAT.

A NEW CYCLE

NEAT R

DEFINING OUR LIGHT E-MTB

THE BALANCED GEOMETRY OF NEAT

NEAT = ANY TYPE OF RIDER AND ANY TYPE OF RIDING

Free UK Delivery

Easy Returns

Free Bike Setup
